The Only UL Listed Smart Splitter on the Market
We know you take protection seriously—we do too. We worked hard to get this product UL Safety Certified so that you can charge with confidence and peace of mind.
Our Smart Splitters™ are quality you can count on, 100% guaranteed.
Smart Features That You'll Love
Automatic Circuit Protection
Charge Notifications
Energy Monitoring
Save Big On Installation
Charge Scheduling
Experience Intelligent Auto-Switching
EV is charging normally.
As the Primary Outlet begins to draw power, the EV pauses charging.
Once the Primary Outlet finishes, the EV resumes charging where it left off.
Specifications
40 Amp Smart Splitter
Output Power
40A/9.6kW
Input Voltage
240 VAC nominal, single phase
Input
NEMA 14-50P or 10-50P
Outputs
2 x NEMA 14-50R or 10-50R
Dimensions
5.25" x 5.25" x 2.8"
Weight
2.5 lbs
Warranty
2 years
Built in the USA
Indoor use only
24 Amp Smart Splitter
Output Power
24A/5.7kW
Input Voltage
240 VAC nominal, single phase
Input
NEMA 14-30P or 10-30R
Outputs
2 x NEMA 14-30R or 10-30R
Dimensions
5.25" x 5.25" x 2.8"
Weight
2.5 lbs
Warranty
2 years
Built in the USA
Indoor use only
Charge Up with Savings
Traditional home charging installation is notoriously expensive and can take hours (sometimes days). Say goodbye to all of your installation headaches with a simple self-installation. Access home charging in minutes and save thousands of dollars with our Smart Splitter™ devices.
Charge Smarter.
Take full advantage of wifi connectivity with the Smart Charging App. Track, schedule, control, and get charging notifications from anywhere.
Compatible with all wifi-enabled Smart Splitter™ devices. Expected to be fully rolled out in June 2021 with an over the air update.
People Love What We've Created
“I provided a customer with a Smart Splitter so he could charge two cars off one NEMA 14-50 outlet I installed last year. When he got his second car, his panel didn't have enough space for a second 240 volt outlet and I charge $3,000 for that kind of panel upgrade. This product saved him thousands of dollars on his setup and I was able to service another customer. Five stars!”
Charlie S.
Electrician
“After I bought my Nissan Leaf, I got quoted $2,357 to get home EV charging installed, but I couldn’t pull the trigger at that price. I’ve been swapping my EV charger and dryer plug and it's been a huge pain to move my dryer every day. I found NeoCharge and I am using the Smart Splitter as a dryer outlet splitter for my nema 1430 outlet! I never have to worry about swapping my cables anymore because the Smart Splitter handles circuit sharing for me.”
Ahraan V.
Nissan Owner
“I drive a Tesla Model Y and my husband drives an Audi e-tron, but we use the same Juicebox 40 to charge our EVs with our nema 1450 outlet. We thought we could get away with just one Level 2 charger by switching the charger late at night, but it was a huge hassle! We really needed to install Tesla home charging and I couldn't find other 240v splitters that had a UL safety certification. I'm so glad we we're able to use the Smart Splitter instead of switching our charger late at night.”
Ameera K.
Tesla Owner
Easy Home Charging Installation
Promo Video
Setup Video
FAQ
What is your return/refund policy? Is there a warranty?
If you are not 100% satisfied with your Smart Splitter, you can return the product for a refund within 30 days of your purchase. Your satisfaction is very important to us!
We also offer a 2-year limited warranty on our Smart Splitters. Please note that this warranty is only valid for use under normal in door residential operating conditions. Using a Smart Splitter outside of normal residential operating conditions, such as for commercial application, voids the warranty.
Is the Smart Splitter Safety Certified?
Yes, the Smart Splitter is UL Listed, which means it adheres to the highest safety standards for electric vehicle equipment.
What outlets are compatible with the Smart Splitter?
NEMA 10-30 (24A)—Dryers from before 1990
NEMA 10-50 (40A)—Electric Ranges
NEMA 14-30 (24A)—Dryers from 1991—now
NEMA 14-50 (40A)—Installed EV Charging Outlets
NEMA 6-50 (40A)—Installed EV Charging Outlets (Coming Soon)
Can both Smart Splitter outlets output power at the same time?
In standard cases, the Smart Splitter will allow one outlet to run at a time giving priority to the device plugged into the primary output of the Smart Splitter.
However, the Dual-Car version has the capability of simultaneously charging both of your cars at once. The Dual-Car version allows you to configure the charge rate in your car or EVSE to charge both cars at the same time. For your safety, the Smart Splitter will prevent exceeding the outlet's rating.
Does the Smart Splitter have a cord?
The Smart Splitter is not a Level 2 charger and does not have a cord. By not having a cord the Smart Splitter is more compact and easily portable. A Level 2 charger plugs-in to the Smart Splitter! Teslas come with a Level 2 charger (the Tesla Mobile Connector), you will just need a Tesla adapter to plug into a NEMA 14-50, NEMA 10-30, or NEMA 14-30 outlet.
Can I customize my output configuration?
In some cases, customization is available. If you would like a custom Smart Splitter, please contact: support@getneocharge.com.
Will the Smart Splitter work with my Tesla(s)?
Yes, the Smart Splitter works with all electric vehicles and pairs very well with Teslas.
What is a Level 2 charger?
Level 2 charging refers to the voltage that the electric vehicle charger uses (240 volts). Level 2 chargers come in a variety of amperages typically ranging from 16 amps to 40 amps. The two most common Level 2 chargers are 16 and 30 amps, which also may be referred to as 3.3 kW and 7.2 kW respectively.
Can I use an adapter to plug into my Smart Splitter?
Yes, you can use an adapter for your EV charger, although we do not recommend using a third-party adapter, these are not often UL safety certified.
What happens if my car tries to charge at 40 Amps on my dryer outlet?
The NeoCharge has a safety mechanism that can detect when there is an overdraw of current and will automatically disable your charge if you are pulling more power than allowed by the outlet.
